Livestream

Purpose

The livestream service is based on the Fink filters. After each exposure, Fink processes the alerts sent by ZTF and the filters select alerts to be transmitted based on their content. These alerts are sent to the Fink Apache Kafka cluster, and substreams are produced (1 filter = 1 substream), identified by their topic name. Each alert pushed is available 7 days in the queue, and consumers can replay streams indefinitely.

As Kafka can be somehow cumbersome, we developed a client to facilitate the stream consuming part for Fink users: fink-client. Users can connect to one or more topics, and new topics can be created via new Fink filters.

Installation of fink-client

To ease the consuming step, the users are recommended to use the fink-client, which is a wrapper around Apache Kafka. fink_client requires a version of Python 3.9+. Documentation to install the client can be found at services/fink_client. Note that you need to be registered in order t o poll data.

Connecting to a topic

For the list of available topics, see https://doc.ztf.fink-broker.org/broker/filters/#available-topics. From version 12, you can also access this list programmatically:

finkctl topic list -survey ztf

Choose the topic(s) you want, and register them:

finkctl topic subscribe -survey ztf -name fink_early_sn_candidates_ztf

You should see it in your configuration:

finkctl auth show -survey ztf

...
survey: ztf
topics:
  fink_early_sn_candidates_ztf:
    telegram:
      channel: null
      token: null
...

Documentation for topics can be accessed from:

finkctl topic

First steps: testing the connection

Processed alerts are stored 4 days on our servers, which means if you forget to poll data, you'll be able to retrieve it up to 4 days after emission. This also means on your first connection, you will have 4 days of alert to retrieve. Before you get all of them, let's retrieve the first available alert to check the connection. On a terminal, run the following

# access help using `finkctl stream -h`
finkctl stream -survey ztf --display -limit 1

# access help using `fink_consumer -h`
fink_consumer -survey ztf --display -limit 1

This will download the first available alert, and print some useful information. The alert schema is automatically downloaded from the alert packet. Then the alert is consumed and you'll move to the next alert. Of course, if you want to keep the data, you need to store it. This can be easily done:

# create a folder to store alerts
mkdir alertDB

finkctl stream -survey ztf --display --save -outdir alertDB -limit 1

# create a folder to store alerts
mkdir alertDB

fink_consumer -survey ztf --display --save -outdir alertDB -limit 1

This will download the next available alert, display some useful information on screen, and save it (Apache Avro format) on disk. Then if all works, then you can remove the limit, and let the consumer run for ever!

finkctl stream -survey ztf --display --save -outdir alertDB

fink_consumer -survey ztf --display --save -outdir alertDB

Inspecting alerts

Once alerts are saved, you can open it and explore the content. We wrote a small utility to quickly visualise it:

# access help using `fink_alert_viewer -h`
# Adapt the filename accordingly -- it is <objectId>_<candid>.avro
fink_alert_viewer -survey ztf -filename alertDB/ZTF21aaqkqwq_1549473362115015004.avro

of course, you can develop your own tools based on this one! Note Apache Avro is not something supported by default in Pandas for example, so we provide a small utilities to load alerts more easily:

from fink_client.avro_utils import AlertReader

# you can also specify one folder with several alerts directly
r = AlertReader('alertDB/ZTF21aaqkqwq_1549473362115015004.avro')

# convert alert to Pandas DataFrame
r.to_pandas()

Managing offsets

Checking offsets

You might want to check where you are on the different queues, that is retrieving the offsets for each topic that you are polling:

finkctl stream -survey ztf --display_statistics

Topic [Partition]                                   Committed        Lag
========================================================================
fink_sso_ztf_candidates_ztf  [4]                            1        972
------------------------------------------------------------------------
Total for fink_sso_ztf_candidates_ztf                       1        972
------------------------------------------------------------------------

Topic [Partition]                                   Committed        Lag
========================================================================
------------------------------------------------------------------------
Total for fink_sso_fink_candidates_ztf                      0          2
------------------------------------------------------------------------

In this example, I have two topics, fink_sso_ztf_candidates_ztf and fink_sso_fink_candidates_ztf.

For the first topic, there is one active partition on the remote Kafka cluster that served data (number [4]). I polled 1 alert (Committed), and there are 972 remaining alerts to be polled (Lag). As there is only one active partition on the remote Kafka cluster, the total is the same (there could be up to 10 active partitions). For the second topic, I did not start polling as 0 alert has been Committed.

Resetting offsets

Sometimes you might want to poll again alerts, that is restarting to poll from the beginning of a queue. For this, you can use:

finkctl stream -survey ztf --display -start_at earliest
Resetting offsets to BEGINNING
...
assign TopicPartition{topic=fink_sso_fink_candidates_ztf,partition=0,offset=0,leader_epoch=None,error=None}
...
assign TopicPartition{topic=fink_sso_ztf_candidates_ztf,partition=0,offset=0,leader_epoch=None,error=None}
...
# poll restarts at the first offset

All your topic partitions will be reset to the starting offset (0 in this case). Similarly, you can empty all topics, and restarting polling from the last offset:

finkctl stream -survey ztf --display -start_at latest
...
assign TopicPartition{topic=fink_sso_fink_candidates_ztf,partition=0,offset=0,leader_epoch=None,error=None}
...
assign TopicPartition{topic=fink_sso_fink_candidates_ztf,partition=4,offset=2,leader_epoch=None,error=None}
...
assign TopicPartition{topic=fink_sso_ztf_candidates_ztf,partition=4,offset=973,leader_epoch=None,error=None}
...
No alerts the last 10 seconds
...

Empty partitions will have offset=0, but others will have their offset to the latest one. The client will then wait for new data to come. Note that the reset will be actually triggered on the next poll. Hence the command finkctl stream --display_statistics will not right away display the reset offsets. This is particularly useful after a bug in the topic (malformed alerts pushed), and you want a fresh restart.

Write your own stream connector

We currently see how to print alerts on the terminal, or save them on disk. We also have a tutorials to create bots that will redirect alerts on instant message applications such as Telegram or Slack. In case you want another connector (e.g. save data directly into a database), you can easily extend finkctl by adding a new handler in fink_client/handlers.py. Do not hesitate to reach us if you need assistance.

Troubleshooting

In case of trouble, send us an email (contact@fink-broker.org) or open an issue https://github.com/astrolabsoftware/fink-client .

Wrong schema

A typical error though would be:

Traceback (most recent call last):
  File "fastavro/_read.pyx", line 835, in fastavro._read.schemaless_reader
  File "fastavro/_read.pyx", line 846, in fastavro._read.schemaless_reader
  File "fastavro/_read.pyx", line 561, in fastavro._read._read_data
  File "fastavro/_read.pyx", line 456, in fastavro._read.read_record
  File "fastavro/_read.pyx", line 559, in fastavro._read._read_data
  File "fastavro/_read.pyx", line 431, in fastavro._read.read_union
  File "fastavro/_read.pyx", line 555, in fastavro._read._read_data
  File "fastavro/_read.pyx", line 349, in fastavro._read.read_array
  File "fastavro/_read.pyx", line 561, in fastavro._read._read_data
  File "fastavro/_read.pyx", line 456, in fastavro._read.read_record
  File "fastavro/_read.pyx", line 559, in fastavro._read._read_data
  File "fastavro/_read.pyx", line 405, in fastavro._read.read_union
IndexError: list index out of range

This error happens when the schema to decode the alert is not matching the alert content. Usually this should not happen (schema is included in the alert payload). In case it happens though, you can force a schema:

finkctl stream [...] -schema [path_to_a_good_schema]

In case you do not have replacement schemas, you can save the current (faulty) schema that is contained within an alert packet:

finkctl stream -survey ztf -limit 1 --dump_schema

You will see the traceback above, with the message:

Schema saved as schema_2024-06-03T11:12:36.855544+00:00.json

Then you can inspect the schema manually, or open an issue on the fink-client repository by attaching this schema to your message.

Authentication error

If you try to poll the servers and get:

%3|1634555965.502|FAIL|rdkafka#consumer-1| [thrd:sasl_plaintext://xx.xx.xx.xx:yy/bootstrap]: sasl_plaintext://xx.xx.xx.xx:yy/bootstrap: SASL SCRAM-SHA-512 mechanism handshake failed: Broker: Request not valid in current SASL state: broker's supported mechanisms:  (after 18ms in state AUTH_HANDSHAKE)

You are likely giving a password when instantiating the consumer. Check your conf:

finkctl auth show -survey ztf

it should not contain any entry called password:.

Timeout error

If you get frequent timeouts while you know there are alerts to poll, try to increase the timeout (in seconds) in your configuration file:

# edit ~/.finkclient/credentials.yml
maxtimeout: 30

In some cases (sorry Australia!), you might even increase it to 120 seconds...We are working on it to reduce these latencies.
